Top Page > Adjustment Item Menu Guide: TCRU/ORU > Details of Menu Items in Adjustment Settings for Skilled Operators > Setting Values: Adjustment Settings for Skilled Operators > 01: Machine: Image Position > 0107: [Perpendicularity Adjustment]
Adjust the vertical skew of the image.
Press [+] to skew the image counterclockwise or [－] to skew it clockwise.
Setting Item
Default Value
Max. Value
Min. Value
Step
Unit
[Perpendicularity Adjustment]
0
20
-20
1
None
